Konami KX43 - P;N 331533 Assy, Cab, Main (Fig. 2 of 3)

SECTION 3 - PARTS, ASSEMBLIES & HARDWARE
1-3-12
3-12 © 2018 Konami Gaming Inc. P/N 810440
KX43
(Original Instructions)
P/N 331533 ASSY, CAB, MAIN (FIG. 2 OF 3)
ITEM PART # DESCRIPTION
1� 110270 GROUND STRAP, 7” (3)
- 110465 HRNS, K3-URV, LED, LINK (NOT SHOWN)
- 110866 HRNS, PDM2, BV (NOT SHOWN)
-� 110867 HRNS, PDM2, PRINTER (NOT SHOWN)
- 111248 HRN, KX43, SPEAKER (NOT SHOWN)
- 111249 HRNS, KX43, BASE (NOT SHOWN)
- 111250 HRNS, KX43, DECK (NOT SHOWN)
- 111251 HRNS, KX43, UPPER (NOT SHOWN)
2� 111258 GROUND STRAP, 30' L (2)
3� 130057 PLUG,RESET KEY (2)
4� 131040 ASSY, WLDMNT, MOUSE HOLE CVR (2)
5� 131213 ASSY� WLDMNT, LATCH RELEASE
6� 131278 ASSY, WLDMNT, CABINET
10� 131293 ASSY, WLDMNT, RS, SPEAKER
11� 131294 ASSY, WLDMNT, LS, SPEAKER
12� 131295 ASSY, WLDT, RS, HLDR, LED SIDE DIFF
13� 131296 ASSY, WLD, LS, HLDR, LED SIDE DIFF
14� 190070 FAN,GUARD,3�25' MOUNTING (2)
20� 191744 CAM, LOCK, DECK
23� 193593 HINGE, BELLY DOORS
25� 193600 BRKT, MTG, ROTARY, LATCH, DECK
26� 193606 BAR, LATCH, MID, BELLY DOOR
27� 193611 BRKT, SWITCH, CHERRY, DECK, BELLY DRS
28� 193613 CAM, LOCK, CASHBOX DOOR
29� 193837 BRKT, STOP, BUMPER (2)
30� 193838 BRKT, MTG, FOOTREST
31� 193839 HINGE, DECK
32� 193840 DOOR, CASHBOX
33� 193842 DOOR, BELLY
34� 193843 BRKT, LCK, BTTM, LATCH, MID BELLY DR
35� 193844 BRKT, LOCK, TP, LTCH, MID, BLLY DOOR
36� 193845 BRKT, MTG, SENSOR
37� 193846 PLT, GUARD, RS, CASHBOX, DOOR
38� 193847 PLT, GUARD, LS, CASHBOX, DOOR
39� 193848 BRKT, MTG, RS, CASHBOX, DOOR
40� 193849 BRKT, MTG, LS, CASHBOX, DOOR
41� 193850 BRKT, CHERRY SWITCH, CASHBOX, DOOR
46� 193912 BRKT, MTG, TWEETER (2)
47� 193984 PLT, GUARD, BELLY DOOR (2)
48� 193985 BRKT, SWITCH, CHERRY, DECK (2)
49� 194003 PLT, SERIAL, KGP KX43, US/CAN
50� 194050 COVER, DECK, LATCH
51� 230007 BUSHING, LATCH, TRAY, COIN (7)
ITEM PART # DESCRIPTION
52� 230110 PIN, LOCK BAR, 1/4-20
53� 230118 BALL STUD, MODIFIED (2)
54� 310025 ASSY, KEYSWITCH, ROTARY, SLIDE
59� 310821 PRINTER, JCM, GEN 5 UNIV
60� 310995 ASSY, FOOTREST
61� 311009 ASSY, DIFF, CAB, SIDE, RS, INJCTN MOLD
62� 311010 ASSY, DIFF, CAB, SIDE, LS, INJCTN MOLD
67� 331536 ASSY, METER
70� 410966 CVR, METER
71� 410971 BEZEL, COVER, SPEAKER (2)
72� 450013 NUT, HEX KEP, 10-32 (8)
74� 450015 NUT, HEX KEP, 6-32 (24)
75� 450016 NUT, HEX KEP, 8-32 (146)
77� 450109 SCREW, SEMS, PAN HEAD PHILLIPS, 6-32 X 1/2
78� 450115
SCREW, SENS, PAN HEAD PHILLIPS, 8·32 X 1/4
(4)
79� 450117
SCREW, SEMS, PAN HEAD PHILLIPS, 8-32 X 3/8
(7)
81� 450127 SCREW, SEMS, PAN HEAD PHILLIPS, M4 X 6 (2)
84� 450163 RIVET, POP, 1/8'DIA X 3/8" LONG (4)
85� 450176 WASHER, #8 FLAT (10)
88� 450282 NUT, HEX, NYLOCK, 8-32 (13)
89� 450285 WASHER, FENDER, #10 OD 1"X7/32 ID X 3/64 (2)
90� 450386 SPRING�EXT, 2�25" FL, �375 OD, �039 WD (3)
91� 450467
SCREW, SEMS, PAN HD, PHILLIPS, 1/4-20 X 1/2
(4)
92� 450471 NUT, HEX, NYLON-INSERT, 1/4-20
95� 450631
LATCH, ROTARY, TWO STAGE, LH, IN-LINE ACT,
1/4-20 THD
96� 450632 BUMPER, THREADED STUD, M6 (4)
98� 450634 NUT� HEX JAM, M6 (4)
99� 450761 GAS SPRING, 485MM 285MM 200N (2)
108� 490044 SWITCH, CHERRY, E79-30A (4)
109� 490065 SENSOR, PHOTO, ALEPH
113� 530054 FAN, LOGIC BOX, 600mm HARNESS (2)
114� 530322 SPEAKER, RECT, 8 OHMS, 7�5 WATTS (2)
116� 530774 HARNESS, TWEETER (2)
117� 710000 LOCK, BARREL, �625 LONG (2)
118� 830079 DECAL,RESET, AUDIT
119� 830080 DECAL, SERVICE PHONE NUMBER
