SECTION 3 - PARTS, ASSEMBLIES & HARDWARE
1-3-26
3-26 © 2018 Konami Gaming Inc. P/N 810440
KX43
(Original Instructions)
GAME POWER CORD OPTIONS
PART # DESCRIPTION
490078 CORD, AC, 7�5’ US/CANADA
490466 CORD, AC, 250V, 10A, IRAM (ARGENTINA)
490467 CORD, AC, 250V, 10A, UK
490468 CORD, AC, 250V, 10A, EUROPE/KOREA
490469 CORD, AC, 250V, 10A, AUSTRALIA
490470 CORD, AC, 250V, 10A, CHILE/ITALY
490514 CORD, AC, IEC320 C14 TO C13
490515 CORD, AC, 250V, 10A, NEMA 6-15P, IEC320-C13
490516 CORD, AC, 250V, 10A, SWITZERLAND
CANDLE TOWER PART NUMBERS
PART # DESCRIPTION
630015 ASSY, TOWER, 2-TIER TALL, GOLD
630026 ASSY, TOWER, 3-TIER SHORT, GOLD
630088 ASSY, TOWER, TWO-TIER, CHROME (TALL)
630089 CANDLE, SHORT, 2 TIER, CHROME (LED)
630090 CANDLE, SHORT, 2 TIER, GOLD (LED)
630091 CANDLE, SHORT, 3 TIER, CHROME (LED)
SIGNAL TOWER FILTERS PART NUMBERS
PART # DESCRIPTION
630001 FILTER, TALL, YELLOW
630002 FILTER, TALL, RED
630005 FILTER, TALL, BLUE
630008 FILTER, TALL, ORANGE
630009 FILTER, TALL, GREEN
630010 FILTER, SHORT, RED
630011 FILTER, SHORT, BLUE
630012 FILTER, SHORT, YELLOW
630013 FILTER, SHORT, GREEN
630014 FILTER, SHORT, ORANGE
630017 FILTER, TALL, BROWN
630018 FILTER, TALL, PINK
630019 FILTER, SHORT, BROWN
630020 FILTER, SHORT, PINK
630021 FILTER, YEL/GRN/BLUE, Multi-Denom
630022 FILTER, YEL/ORG/BLUE, Multi-Denom
630023 FILTER, TWO-TIER, SHORT, PURPLE
630024 FILTER, TWO-TIER, TALL, PURPLE
630029 FILTER, TRIPLE, RED/WHT/RED
630030 FILTER, TRIPLE, RED/WHT/YEL
630031 FILTER, TRIPLE, RED/WHT/GREY
P/N 310375 ASSY, BV, JCM IVIZION, 1000 NOTE,
72MM
3
2
1
ITEM PART # DESCRIPTION
1� 310338 HEAD, BV
2� 310339 TRANSPORT, BV
3� 310343 BILL BOX, 1000 NOTE, JCM IVIZION
P/N 310821 PRT, FUTURE LOGIC, GEN5,
UNIVERSAL
