TECHNICAL DATA - CHASSIS 173
Frame Lattice frame made of chrome molybdenum steel tubing,
powder-coated
Fork WP Suspension Up Side Down 4860 ROMA
Shock absorber WP Suspension 4618 with Pro‑Lever deflector
Suspension travel
Front 275 mm (10.83 in)
Rear 265 mm (10.43 in)
Brake system
Front Disc brake with radially screwed four-piston brake caliper, float-
ing brake disc
Rear Disc brake with single-piston brake caliper, floating
Brake discs - diameter
Front 320 mm (12.6 in)
Rear 240 mm (9.45 in)
Brake discs - wear limit
Front 4.0 mm (0.157 in)
Rear 4.5 mm (0.177 in)
Tire air pressure, solo
Front 2.0 bar (29 psi)
Rear 2.0 bar (29 psi)
Tire air pressure with passenger / fully loaded
Front 2.0 bar (29 psi)
Rear 2.2 bar (32 psi)
Secondary drive ratio 16:42
Chain 5/8 x 1/4” X‑ring
Steering head angle 63°
Wheelbase 1,480±15 mm (58.27±0.59 in)
Seat height unloaded 900 mm (35.43 in)
Ground clearance unloaded 290 mm (11.42 in)
Weight without fuel approx. 139.5 kg (307.5 lb.)
Maximum permissible front axle load 150 kg (331 lb.)
Maximum permissible rear axle load 200 kg (441 lb.)
Maximum permissible overall weight 350 kg (772 lb.)
Battery YTZ10S Battery voltage: 12 V
Nominal capacity: 8.6 Ah
maintenance-free
Fuse 58011109130 30 A
Fuse 75011088015 15 A
Fuse 75011088010 10 A
28.1Lighting equipment
Headlight H4 / socket P43t 12 V
60/55 W
Parking light W5W / socket W2.1x9.5d 12 V
5 W
Instrument lights and indicator lamps LED
Turn signal RY10W / socket BAU15s 12 V
10 W
Brake/tail light (690 SMC EU,
690 SMC AUS/UK)
LED
Brake/tail light (690 SMC USA) P21/5W / socket BAY15d 12 V
21/5 W
