30/ENGINE 89
– Take off the clutch push rod.
300216-10
– Unscrew the electrical connection from the starter motor.
– Remove ground wire from the starter motor.
300217-10
– Loosen hose clip .
– Pull off the throttle valve body from the rear.
300218-10
– Disconnect plug-in connections of the gear position sensor, the crankshaft posi-
tion sensor and the alternator.
– Remove the cable binders and release the cables.
300188-10
– Pull of the spark plug connector.
– Unplug the connector of the engine coolant temperature sensor .
300220-10
– Loosen the spring-loaded band-type clamp from the breather, SLS and oil return
line with the special tool.
Pliers for spring-loaded band-type clamp (60029057100) ( p. 210)
300221-10
– Remove screws . Remove the engine bearer.
