KYMCO MX 125 - Service Information

12. FRONT WHEEL/FRONT BRAKE/FRONT
SUSPENSION/STEERING SYSTEM
12-2
MX’er SYSTEM
SERVICE INFORMATION
GENERAL INSTRUCTIONS
• Remove the machine frame covers before removing the front wheel. Jack the machine front
wheel off the ground and be careful to prevent the machine from falling down.
• During servicing, keep oil or grease off the brake drum and brake linings.
• Inspect the brake system before riding.
SPECIFICATIONS
Ite
m
Standard
(
mm
)
Service Limit
(
mm
)
Radial
⎯
2.0
Axial
⎯
2.0
Front brake drum I.D 110 111
Front brake linin
g
thickness 4 1.5
Tie rod len
g
th 266.5
⎯
Ro
d
-end
(
tie rod
)
an
g
le 180
º
⎯
Front wheel rim run out
TORQUE VALUES
Steering stem nut 6.08.0kgf-m
Swing arm nut 4.05.0kgf-m
Front wheel nut 6.08.0kgf-m
Front wheel hub nut 6.08.0kgf-m
Front shock absorber upper
mount bolt 3.54.5kgf-m
Front shock absorber lower
mount bolt 3.54.5kgf-m
