KYMCO MX 125 - Torque Values

1. GENERAL INFORMATION
1-12
MX’er SYSTEM
TORQUE VALUES
STANDARD TORQUE VALUES
Ite
m
Torque (k
g
f-m) Ite
m
Torque (k
g
f-m)
5mm bolt, nut
6mm bolt, nut
8mm bolt, nut
10mm bolt, nut
12mm bolt, nut
14mm bolt, nut
0.450.6
0.81.2
1.82.5
3.04.0
5.06.0
6.08.0
4mm screw
5mm screw
6mm screw, SH bolt
6mm flange bolt and nut
8mm flange bolt and nut
10mm flange bolt and nut
0.150.4
0.30.5
0.71.1
1.01.4
2.43.0
3.54.5
Torque specifications listed below are for important fasteners.
ENGINE
Item Q‘ty Thread dia.(mm) Torque (kgf-m) Remarks
Stud bolt
Oil filter screen cap
Seat ball stopper bolt
Bearing hold
L cover
Stud bolt
Cam holder
Tappet ADJ nut
Pivot tensioner
Lifter tensioner
Lifter tensioner
MISTON oil drive bolt
Driver face
Clutch outer
Oneway clutch
Balancer shaft
ACG flywheel
Spark plug
Drain bolt mission
Drain plug
Clamper wre harness
Motor srart
Oil pump
Oil pump sprocket
Head CYL bolt
Drive plate nut
Startor
4
1
1
1
8
4
4
2
1
2
1
9
1
1
3
1
1
1
1
1
1
2
2
2
2
1
4
8
30
14
6
6
6
8
6
8
6
6
6
12
12
8
16
14
8
8
12
6
6
6
6
6
22
5
0.71.1
1.02.0
4.55.0
1.01.2
1.01.4
0.71.1
1.82.2
1.41.8
0.81.2
1.01.4
0.350.5
0.81.2
5.56.5
5.06.0
2.43.0
4.05.0
5.06.0
1.12.3
0.81.2
2.03.0
0.81.2
0.81.2
0.81.2
0.81.2
0.81.2
5.06.0
0.81.2
