KYMCO MX 125 - Hazard Switch; Horn

18. ONLY ATV ON ROAD AVAILABLE
18-4
MX’er SYSTEM
Remove the bulb socket and bulb.
Check the bulb for damage and replace with
a new one if necessary.
INSTALLATION
The installation sequence is the reverse of
removal.
HAZARD SWITCH
Check for continuity between the wires
indicated below.
Color
Position
Yellow
/Black
Black
○ ○
●
HORN
REMOVAL
Disconnect the horn switch wire.
Remove the bolt and remove horn.
INSTALLATION
The installation sequence is the reverse of
removal.
Bulb Socket
Bulb
Hazard Switch
Bolt
Horn Switch wire
