1. GENERAL INFORMATION
1-18
MX’er SYSTEM
CABLE & HARNESS ROUTING
Rear Brake Cable
Throttle Cable
Front Brake Cable
Handlebar Switch Lea
d
Right Front Brake Cable
Left Front Brake Cable
