5. FUEL SYSTEM
5-9
MX’er SYSTEM
Tighten the choke cable.
FUEL TANK
FUEL TANK REMOVAL
Remove the seat.
Remove the center cover.
Remove the right and left front fender.
Switch the fuel valve “OFF”.
Disconnect the fuel tube and remove two
bolts on the end of the fuel tank.
Remove the fuel tank.
FUEL VALVE REMOVAL
Remove the fuel valve and fuel cup.
Screw
Choke Cable
Bolts
Fuel Tank
Fuel Valve
Tube
Side
• Keep sparks and flames away from the
work area.
• Wipe off any spilled gasoline.
