15. IGNITION SYSTEM
15-1
MX’er SYSTEM
Ignition Switch
CDI Uni
t
/Change Gear Control.
l
A.C. Generato
r
/
Pulser Coil
Spark Plug
Ignition Coil
IGNITION CIRCUIT
PULSER COIL
