3. INSPECTION/ADJUSTMENT
3-15
MX’er SYSTEM
Turn out: Slack is decreased.
Turn in: Slack is increased.
Tighten four bolts attaching rear axle hub to
the specification. While pushing up or down
on the chain to zero slack.
Torque: 6.08.0kgf-m
Tighten the adjuster.
Torque: 1.82.5kgf-m
Bolts
Adjuste
r
CABLE INSPECTION AND
LUBRICATION
Adjuste
r

Damaged cable sheath may cause
corrosion and interfere with the cable
movement. An unsafe condition may
result so replace such cable as soon as
possible.
