2. FRAME COVERS/EXHAUST MUFFLER
2-3
MX’er SYSTEM
FRAME COVERS
SEAT REMOVAL
Pull the lever backward, then pull up the
seat at the rear.
Remove the seat.
LEFT REAR FENDER REMOVAL
Remove seven screws and two bolts
attaching the left rear fender.
Remove the left rear fender under bolt.
Remove the left rear fender.
RIGHT REAR FENDER REMOVAL
Remove seven screws and two bolts
attaching the right rear fender.
Sea
t
Screws
Frame Lef
t
Cove
r
Bol
t
Bol
t

During rem
Bol
t
Frame Ri
g
h
t
Cove
r
During removal, do not pull the joint
claws forcedly to avoid damage.

oval, do not pull the joint
aclaws forcedly to avoid dam ge.
