1. GENERAL INFORMATION
1-17
MX’er SYSTEM
Swing arm Thrust
Cove
r
Rear Brake Cam/
Axle Hub Collar/Oil
Seal/Bearing
Sprocket hub/Rear
Axle Hub Collar/Oil
Seal/Bearing
Driven Sprocket
