15. IGNITION SYSTEM
15-4
MX’er SYSTEM
CDI unit.
Measure the resistance between the
terminals using the electric tester.
.
Testing Range
Use the xKΩ range for the Sanwa Tester.
Use the xKΩ range for the Kowa Tester.
Note: The readings in this table are taken
with a Sanwa Tester.
• Due to the semiconductor in circuit, it is
necessary to use a specified tester for
accurate testing. Use of an improper
tester in an improper range may give
false readings.
• Use a Sanwa Electric Tester or Kowa
Electric Tester.
• In this table, “Needle swings then
returns” indicates that there is a charging
current applied to a condenser. The needle
will then remain at “∞” unless the
condenser is discharged.

Unit: KΩ
Test the CDI unit using the CDI tester.
Black
/
White
Blue/Yellow
CDI Uni
t
Black/Red
Black/Yellow
Green/Red
Green/White
Probe⊕
(-)Probe
Black/
White
Black/
Red
Blue/
White
Green
Green/
White
Black/
Yellow
Black/
White
∞ ∞ ∞ ∞ ∞
Black/
Red
3-6K
∞ ∞
∞ ∞
Blue/
White
35-42K 18-22K 8-10K 8-10K ∞
Green
15-18K 4.5-5.5K 7-9K
There is
continuity
∞
Green/
White
15-18K 4.5-5.5K 8-9K
There is
continuity
∞
Black/
∞ ∞
∞
∞
∞
Needle
Swings then
Needle
Swings then
Change Gear Control

Operate the CDI tester by following the
manufacturer‘s instructions.
