15. IGNITION SYSTEM
15-7
MX’er SYSTEM
Remove the front cover.
Disconnect the pulser coil wire coupler and
measure the resistance between the blue/
yellow and green/white wire terminals.
Resistance: 5060Ω
EXCITER COIL
INSPECTION
Disconnect the exciter coil wire coupler and
measure the resistance between the
black/red wire terminal and ground.
Resistance: 100120Ω
