3. INSPECTION/ADJUSTMENT
3-8
MX’er SYSTEM
Remove the oil dipstick and check the oil
level with the oil dipstick.
If the level is near the lower level, fill to the
upper level with the specified engine oil.
OIL CHANGE
Remove the oil drain plug bolt located on
the bottom of the engine to drain the engine
oil thoroughly.
After the oil has been completely drained,
Install the oil drain plug bolt.
Torque: 2..03.0kgf-m
Recommended Oil: SAE30#
FINAL REDUCTION GEAR OIL
Recommended Oil: GEAR OIL SAE90#
GEAR OIL CHANGE
Remove the oil filler bolt.
Removes the oil drains bolt and drain the oil
Oil Fille
r
Bol
t
Place the motorcycle on level g
r
ound for
oil level check.

Oil Dipstick
Oil Filter Screen Cap
Lower Level
Upper Level
• Place the motorcycle upright on level
ground for engine oil level check.
• Run the engine for 23 minutes and
check the oil level after the engine is
stopped for 23 minutes.
The engine oil will drain more easily
while the engine is warm.

oil drain
p
lu
g
bol
t
