KYMCO MX 125 - Page 50

3. INSPECTION/ADJUSTMENT
3-13
MX’er SYSTEM
TIRE PRESSURE
1 Rider
Front 0.20kgf/cm²
Rear 0.25kgf/cm²
TIRE SIZE
Front : 20*7-8
Rear : 22*10-8
Check the front axle nut for looseness.
Check the rear axle nut for looseness.
If the axle nuts are loose, tighten them to the
specified torque.
Torque: Front : 6.08.0kgf-m
Rear : 6.08.0kgf-m
WHEEL INSPECTION
Inspect the tire surfaces.
Replace if wear or damage.
Tire wear limit: 3.0mm
Inspect the wheel.
Replace if damage or bends
Always balance the wheel when a tire or
wheel has been changed or replaced.
Front Axle Nu
t

Tire pressure should be checked when
tires are cold.
Rea
r
Axle Nu
t
It is dangerous to ride with a worn out
tire. When a tire wear is out of
specification, replace the tire
immediately.

•
Never attempt even small repairs to the
wheel.
• Ride conservatively after installing a
tire to allow it to seat itself properly on

the rim.
