6. ENGINE REMOVAL/INSTALLATION
6-4
MX’er 50
ENGINE REMOVAL
Remove the engine any connector thing.
Remove the engine back bracket bolt, nut
and collar.
Remove the engine front right bracket bolt
and nut.
Remove the engine front left bracket bolt
and nut.
ENGINE INSTALLATION
Install the engine and tighten the engine
mounting bolts.
Torque: 3.5_ 4.5kgf-m
Install the removed parts in the reverse
order of removal.
Bolt
Bolt
Nut
Route the wires and cables properly.
