4.4 Clearing Paper Jams
4-18
3
33
3
Swing the green-colored lever to the right. Remove the jammed paper, if any, inside
the cover.
Figure 4-9
4
44
4
If there is jammed paper on the rubber belts (black) in the middle of the paper
transfer unit, remove the paper.
Figure 4-10
Rubber Belts
