4.4 Clearing Paper Jams
4-19
5
55
5
If the paper is jammed in the fuser unit, open the fuser access cover by pressing the
green-colored lock lever.
The fuser unit is hot. Wait for a while until the fuser unit cools down.
Figure 4-11
6
66
6
Open the fuser top cover. Remove the jammed paper.
Figure 4-12
Caution
Fuser Access Cover
Lock Lever
(Green-colored)
Top Cover
