Kyocera FS-6970DN Service Manual

2J5
2-3-5
Connector Pin Signal I/O Voltage Description
YC5 1 OPSDO O 0/5 V DC (pulse) Paper feeder serial communication data output signal
Connected
to the con-
nect-L PWB
(YC7)
2 +24V2 I 24 V DC 24 V DC power source (via interlock switch)
3 +24V2 I 24 V DC 24 V DC power source (via interlock switch)
4 GND - - Ground
5 GND - - Ground
6 GND - - Ground
7 GND - - Ground
8 GND - - Ground
9 +24V1 I 24 V DC 24 V DC power source
10 +5V1 I 5 V DC 5 V DC power source
11 +5V1 I 5 V DC 5 V DC power source
12 +5V1 I 5 V DC 5 V DC power source
13 +5V2 I 5 V DC 5 V DC power source
YC501 1 +24V4 O 24 V DC 24 V DC power source
Connected
to the main
motor
2 GND - - Ground
3 MMOTONN O 0/5 V DC Main motor: On/Off
4 MMOTRDYN I 0/5 V DC Main motor ready signal
5 MMOTCLK O 0/5 V DC (pulse) Main motor clock signal
YC502 1 DUDRN O 0/24 V DC Duplex clutch: On/Off
Connected
to the con-
nect-R PWB
(YC2)
2 DLPDRN O 0/24 V DC Developer solenoid: On/Off
3 MIDDRN O 0/24 V DC Middle feed clutch: On/Off
4 +24V2 O 24 V DC 24 V DC power source
5 +24V2 O 24 V DC 24 V DC power source
6 REGDRN O 0/24 V DC Registration clutch: On/Off
7 FEEDDRN O 0/24 V DC Paper feed clutch: On/Off
8 EXITFAN O 0/24 V DC Exit fan motor: On/Off
YC503 1 HEATONN2 O 0/5 V DC Fuser heater lamp S: On/Off
Connected
to the con-
nect-L PWB
(YC8)
2 HEATONN1 O 0/5 V DC Fuser heater lamp M: On/Off
3 ZCROSS I 0/5 V DC (pulse) Zero cross signal
4 SWSLEEPN O 0/5 V DC Sleep mode: On/Off
5 HANDSN I 0/5 V DC MP tray paper feed sensor: On/Off
6 HPAP - - Not used
7 SWFAN O 0/24 V DC PSU fan motor: On/Off
8 CASET I 0 to 2.5 V DC Cassette size switch detection voltage (8 levels)
9 TNMOT O 24/0V DC Toner motor: On/Off
10 TNLEVEL I Analog Toner sensor detection voltage
YC504 1 OPSDI I 0/5 V DC (pulse)
Paper feeder serial communication data input signal
Connected
to the con-
nect-L PWB
(YC6)
2 OPSEL2 O 0/5 V DC Paper feeder selection signal (2)
3 OPSEL1 O 0/5 V DC Paper feeder selection signal (1)
4 OPSEL0 O 0/5 V DC Paper feeder selection signal (0)
5 OPRDYN I 0/5 V DC Paper feeder READY signal
6 OPSCLK O 0/5 V DC (pulse) Paper feeder serial communication clock signal
7 WTNLEDN O 0/5 V DC (pulse) Waste toner sensor (light emission) control signal
8 ERASER O 24/0 V DC Eraser lamp: On/Off
9 EEDIO I/O 0/5 V DC (pulse) Drum PWB EEPROM data input/output signal
10 EECLK O 0/5 V DC (pulse) Drum PWB EEPROM clock signal
11 LFANDRN O 0/12/24 V DC Left fan motor: Full speed/Half speed/Off
12 WTNFUL I 0/5 V DC (pulse) Waste toner sensor detection signal

Kyocera FS-6970DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Processor model	440
Processor family	PowerPC
Maximum internal memory	1152 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	51 dB
Power requirements	AC 220-240 V, 50/60 Hz
Total input capacity	350 sheets
Total output capacity	250 sheets
Maximum input capacity	1350 sheets
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 450 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Ledger (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 220 g/m²
Security algorithms	802.1x RADIUS, SSL/TLS
Mobile printing technologies	Not supported
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	9.6 W
Power consumption (printing)	516 W
Power consumption (PowerSave)	6.3 W
Certification	GS, TÜV, CE
Product color	Black, Grey
Printing colors	Black
Maximum duty cycle	150000 pages per month
Recommended duty cycle	20000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PostScript 3
Standard interfaces	Ethernet, Parallel, USB 2.0
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	469 x 395 x 285 mm
