Kyocera FS-6970DN Service Manual

2J5
1-3-4
Detail of service status page
Maintenance items Description
No. Items Description
 Firmware version
-

Engine software version -
 Engine boot version -

Main ROM version
-
 Panel mask version -
 Used memory -
 Local time zone -
 Toner coverage Number of pages printed converted in reference to A4 or Letter size.
 FRPO settings -
 Machine serial No. -
 NVRAM version _ 1F3 1225 _ 1F3 1225
(a) (b) (c) (d) (e) (f)
a) Consistency of the present software version and the database
_ (underscore): OK
* (Asterisk): NG
(b) Database version
(c) The oldest time stamp of database version
(d) Consistency of the present software version and the ME firmware ver-
sion
_ (underscore): OK
* (Asterisk): NG
(e) ME firmware version
(f) The oldest time stamp of the ME database version
Normal if (a) and (d) are underscored, and (b) and (e) are identical with (c)
and (f).
 Destination information -
 Area information -
 Margin settings Top margin/Left margin
 Top offset for each paper
source
MP tray/Paper feeder 1/Paper feeder 2/Paper feeder 3/
Paper feeder 4/Duplex/Page rotation
 Left offset for each paper
source
MP tray/Paper feeder 1/Paper feeder 2/Paper feeder 3/
Paper feeder 4/Duplex/Page rotation
 L value settings Top margin (integer)/Top margin (decimal place)/Left margin (integer)/Left
margin (decimal place)/Paper length (integer)/Paper length (decimal place)/
Paper width (integer)/Paper width (decimal place)

Kyocera FS-6970DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Processor model	440
Processor family	PowerPC
Maximum internal memory	1152 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	51 dB
Power requirements	AC 220-240 V, 50/60 Hz
Total input capacity	350 sheets
Total output capacity	250 sheets
Maximum input capacity	1350 sheets
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 450 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Ledger (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 220 g/m²
Security algorithms	802.1x RADIUS, SSL/TLS
Mobile printing technologies	Not supported
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	9.6 W
Power consumption (printing)	516 W
Power consumption (PowerSave)	6.3 W
Certification	GS, TÜV, CE
Product color	Black, Grey
Printing colors	Black
Maximum duty cycle	150000 pages per month
Recommended duty cycle	20000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PostScript 3
Standard interfaces	Ethernet, Parallel, USB 2.0
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	469 x 395 x 285 mm
