2J5
1-2-5
1-2-7 Installing the hard disk (optional)
<Procedure>
1. Turn off the printer and disconnect the
power cord and printer cable.
2. Remove two screws and then open the
option interface slot cover.
3. Install the hard disk into the option interface
slot.
4. Refit the optional interface slot cover by two
screws.
Figure 1-2-6
Screws
Option interface
slot cover
Hard disk
To Next Page
