2J5
1-5-3
1-5-2 Outer covers
(1) Detaching and refitting the top cover
Procedure
1. Open the top cover.
2. Remove two screws.
3. Remove the connector and then remove the
top cover.
Figure 1-5-3
Screw
Screw
Connector
Top cover
