Kyocera FS-6970DN Service Manual

2J5
1-3-1
1-3 Maintenance Mode
1-3-1 Maintenance mode
The printer is equipped with a maintenance function which can be used to maintain and service the machine.
(1) Executing a maintenance item
>>Developer
>>Maintenance
>>Drum
>>DRUM-CTRL
Ready
Report Print >
Adjust/ >
Maintenance
>Restart
Printer
>Service >
>>Print
Status Page
>>Print Network
Status Page
>>Print
Test Page
>>Write Data
 Press the MENU key.
Message display
To print a status page for service purpose.
To print a network status page.
Prints a test page which contains halftone.
To write data into a USB memory.
T
o reset counter for the maintenance kit.
To initialize the developing unit. (toner install mode)
To perform a automatic drum refreshing.
To perform a drum refreshing.
 Press the  or  key several
times
until [Adjust/Maintenance >] is displayed.
Maintenance mode items
 Press the  key.
 Press the  key.
 Press the  or  key several times
until [>Service >] is displayed.
To scroll these
items,
press the  or  key
repeatedly.
(See page P.1-3-2)
(See page P.1-3-6)
(See page P.1-3-7)
(See page P.1-3-7)
(See page P.1-3-8)
(See page P.1-3-8)
(See page P.1-3-9)
(See page P.1-3-9)
