Kyocera FS-6970DN Service Manual

2J5
1-4-15
(6)
Defective message
displaying (LCD) [2].
No message appears
on the message dis-
play (LCD), even
thought the mes-
sage background
does not illuminate
faintly. (The power is
not supplied to the
operation panel
PWB.)
Broken power cord. Replace the power cord.
The power cord is not
plugged in properly.
Check the contact between the printer’s AC inlet and the AC
power outlet.
No electricity at the AC
power outlet.
Measure the AC input voltage.
Defective power source
unit.
Replace the power source unit (See page P.1-5-29).
Defective harness between
operation panel PWB (YC1)
and main PWB (YC7), or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Defective operation panel
PWB.
Replace the operation panel PWB.
Defective main PWB. Replace the main PWB (See page P.1-5-27).
(7)
"Close rear unit" dis-
play is not cancelled
to closing the rear
unit.
Defective fuser unit’s
drawer connector.
If a fuser unit which is known to work normally is available for
check, replace the current fuser unit in the printer with the normal
one. If the symptom disappears, replace the fuser unit with a new
one.
Defective harness between
engine PWB (YC506) and
fuser drawer connector, or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Defective engine PWB. Replace the engine PWB (See page P.1-5-23).
(8)
"Close top cover" dis-
play is not cancelled
to closing the top
cover.
Deformed interlock switch's
actuator lever.
Check the bending of the actuator lever of the interlock switch, if
there is trouble, remedy or replace.
Defective power source
unit.
Replace the power source unit (See page P.1-5-29).
Defective engine PWB. Replace the engine PWB (See page P.1-5-23).
(9)
"Close left side
cover" display is not
cancelled to closing
the left side cover.
Defective engine PWB. Replace the engine PWB (See page P.1-5-23).
Problem Causes Check procedures/corrective measures

Kyocera FS-6970DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Processor model	440
Processor family	PowerPC
Maximum internal memory	1152 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	51 dB
Power requirements	AC 220-240 V, 50/60 Hz
Total input capacity	350 sheets
Total output capacity	250 sheets
Maximum input capacity	1350 sheets
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 450 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Ledger (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 220 g/m²
Security algorithms	802.1x RADIUS, SSL/TLS
Mobile printing technologies	Not supported
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	9.6 W
Power consumption (printing)	516 W
Power consumption (PowerSave)	6.3 W
Certification	GS, TÜV, CE
Product color	Black, Grey
Printing colors	Black
Maximum duty cycle	150000 pages per month
Recommended duty cycle	20000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PostScript 3
Standard interfaces	Ethernet, Parallel, USB 2.0
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	469 x 395 x 285 mm
