Kyocera FS-C8500DN Service Manual

2KA
1-4-18
(29)
A paper jam in
optional document
finisher is indicated
during copying (right
sub tray eject jam).
Jam code 84
Defective eject switch 2. Run maintenance item U241 and turn eject switch 2 on and off
manually. Replace the switch if indication of the corresponding
switch is not displayed in reverse.
(30)
A paper jam in
optional document
finisher is indicated
during copying (left
sub tray eject jam).
Jam code 85
Defective eject switch 3. Run maintenance item U241 and turn eject switch 3 on and off
manually. Replace the switch if indication of the corresponding
switch is not displayed in reverse.
(31)
A paper jam in
optional document
finisher is indicated
during copying (inner
tray paper entry sen-
sor 2 jam).
Jam code 87
Defective inner tray paper
entry sensor 2.
Run maintenance item U241 and turn inner tray paper entry sen-
sor 2 on and off manually. Replace the switch if indication of the
corresponding switch is not displayed in reverse.
(32)
A paper jam in
optional document
finisher is indicated
during copying (main
tray eject jam).
Jam code 88
Defective eject switch 1. Run maintenance item U241 and turn eject switch 1 on and off
manually. Replace the switch if indication of the corresponding
switch is not displayed in reverse.
(33)
A paper jam in
optional document
finisher is indicated
during copying (cen-
ter-folding unit jam).
Jam code 89
Defective sensor/switch. Run maintenance item U241 and turn the following switch on and
off manually. Replace the switch if indication of the corresponding
switch is not displayed in reverse.
Centerfold paper entry sensor, centerfold eject switch, centerfold
paper conveying sensor
(34)
A paper jam in
optional document
finisher is indicated
during copying (mail-
box jam).
Jam code 90
Defective tray eject sensor. Run maintenance item U241 and turn tray eject sensor on and off
manually. Replace the switch if indication of the corresponding
switch is not displayed in reverse.
Problem
Causes/check procedures Corrective measures

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
