L-Acoustics dV-SUB - Figure 30: L-ACOUSTICS Rk122 A Amplifier Rack Channel Assignments and Cabling; Figure 31: L- L-ACOUSTICS Rk124 A Amplifier Rack Channel Assignments and Cabling; Table 13 B: DV-DOSC DSP Output Channel Assignment and COMB Connector Summary (4+2 Format Presets)

dV-DOSC dV-SUB Manual V3.0 June 2005 45
Table 13b: dV-DOSC DSP output channel assignment
and COMB connector summary (4+2 format presets)
DSP OUTPUT 4+2 FORMAT CO6 / CO24 COMB CONNECTOR
CHANNEL PRESET INPUT 3-WAY SUB 2-WAY*
1 SUB (A) 1 SB118 or SB218
2 LO (A) 2 dV-SUB
3MID (A)3dV-DOSC LO
4 HI (A) 4 dV-DOSC HI
5 2W LO (B) 5 2-way LO
62W HI (B)6 2-way HI
* 2-WAY ENCLOSURES: ARCS, 112XT, 115XT, 115XT HiQ
Operating modes, amplifier rack channel assignments and cabling plus loudspeaker enclosure
combinations for the L-ACOUSTICS RK122a amplifier rack (PADO2a plus 2 x LA48a) are as follows:
dV-DOSC HI dV-SUB SUB SUB 2W HI 2W HI
dV-DOSC LO dV-SUB SUB SUB 2W LO 2W LO
3-WAY SUB 2-WAY
DO10/DO25 + DO3WFILL DO10P+DOSUB DO10/DO25 + DOFILL
or or or
3 x SP10/SP25 4 x SP10/SP25 2 x SP10/SP25
3 dV-DOSC (LA48a) 4 SB218 (LA48a) 6 ARCS / XT
2 dV-SUB (LA48a) or
8 SB118 (LA48a)
Figure 30: L-ACOUSTICS RK122a amplifier rack channel assignments and cabling
Operating modes, amplifier rack channel assignments and cabling plus loudspeaker enclosure
combinations for the L-ACOUSTICS RK124a amplifier rack (PADO4a plus 4 x LA48a) are as follows:
dV-DOSC HI dV-DOSC HI SUB SUB 2W HI 2W HI
dV-DOSC LO dV-DOSC LO SUB SUB 2W LO 2W LO
dV-SUB dV-SUB SUB SUB 2W HI 2W HI
dV-SUB dV-SUB SUB SUB 2W LO 2W LO
3-WAY SUB 2-WAY
3-WAY SUB 2-WAY
DO10/DO25 DO10/DO25 (DO10P+) DO2W (DO10P+) DO2W
+ + (DO10P+) (DO10P +) or or
DO3WFILL DO3WFILL DOSUB DOSUB DO10/DO25 + DOFILL DO10/DO25 + DOFILL
or or
DO2W+CC4FB+SP10/25 DO2W+CC4FB+SP10/25
3 dV-DOSC (LA48a) 3 dV-DOSC (LA48a) 4 SB218 (LA48a) 4 SB218 (LA48a)
2 dV-SUB (LA48a) 2 dV-SUB (LA48a) or 8 SB118 or 8 SB118
6 dV-DOSC / ARCS / XT 6 dV-DOSC / ARCS / XT
Figure 31: L- L-ACOUSTICS RK124a amplifier rack channel assignments and cabling
