dV-DOSC dV-SUB Manual V3.0 June 2005 46
To power 2-way fill enclosures or 3-way stereo dV-DOSC, ARCS or XT systems using PADO2a and
PADO4a amplifier panels, additional COMB connectors can be employed: 2W(A), 2W(B), 3W(A),
3W(B), SUB(A), SUB(B) or 2W STEREO. DSP output channel assignments for 2-way stereo and 3-way
stereo format presets, CO6 or CO24 patching and COMB connector channel selection are
summarized as follows:
Table 14: 2-way and 3-way stereo preset DSP output channel assignment and COMB connector summary
DSP OUTPUT 2W STEREO 3W STEREO CO6 / CO24 COMB CONNECTOR CHANNEL SELECTION
CHANNEL PRESET PRESET INPUT SUB (A) 2W (A) SUB (B) 2W (B) 2W STEREO 3W (A) 3W (B)
1SUB(A)1SUB (A) SUB (A)
2 LO (A) LO (A) 2 LO (A) LO (A) LO (A)
3 HI (A) HI (A) 3 HI (A) HI (A) HI (A)
4 SUB (B) 4 SUB (B) SUB (B)
5 LO (B) LO (B) 5 LO (B) LO (B) LO (B)
6 HI (B) HI (B) 6 HI (B) HI (B) HI (B)
This signal distribution scheme allows for logical patching between digital signal processor outputs and
CO6 or CO24 inputs for 2-way stereo and 3-way stereo format presets, i.e., channels are patched
1:1, 2:2, 3:3 etc. This helps eliminate potential sources of error due to mispatching and, in addition, it
is not necessary to repatch DSP outputs when changing between stereo 2-way and 3-way presets.
Operating modes, amplifier rack channel assignments and cabling plus loudspeaker enclosure
combinations for the L-ACOUSTICS RK122a amplifier rack (PADO2a plus 2 x LA48a) are as follows:
1
2 LO (A) HI (A) HI (B) HI (A) HI (A) HI (B) HI (B)
3HI (A)
4
5 LO (B) LO (A) LO (B) LO (A) LO (A) LO (B) LO (B)
6HI (B)
2W ST 2W (A) 2W (B)
DO10/DO25 + DOFILL DO10/DO25 + DOFILL DO10/DO25 + DOFILL
or or or
2 x SP10/SP25 2 x SP10/SP25 2 x SP10/SP25
3+3 dV-DOSC / ARCS / XT 3+3 dV-DOSC / ARCS / XT 3+3 dV-DOSC / ARCS / XT
Figure 32: L-ACOUSTICS RK122a amplifier rack channel assignments
and cabling for 2-way stereo presets
1SUB (A)
2 LO (A) HI (A) SUB (A) HI (B) SUB (B) SUB (A) SUB (A) SUB (B) SUB (B)
3HI (A)
4SUB (B)
5 LO (B) LO (A) SUB (A) LO (B) SUB (B) SUB (A) SUB (A) SUB (B) SUB (B)
6HI (B)
3W (A) 3W (B) SUB (A) SUB (B)
DO10/DO25 + DO3WFILL DO10/DO25 + DO3WFILL DO10P+DOSUB DO10P+DOSUB
or or or or
3 x SP10/SP25 3 x SP10/SP25 4 x SP10/SP25 4 x SP10/SP25
3 dV-DOSC / ARCS / XT 3 dV-DOSC / ARCS / XT 4 SB218 / dV-SUB(LA48a) 4 SB218 / dV-SUB(LA48a)
2 SB218/dV-SUB or 4 SB118 2 SB218/dV-SUB or 4 SB118 or or
8 SB118 (LA48a) 8 SB118 (LA48a)
Figure 33: L-ACOUSTICS RK122a amplifier rack channel assignments
and cabling for 3-way stereo presets
