LACO ORIGINAL OPERATING INSTRUCTIONS TITANTEST™
81
© 2018 LACO TECHNOLOGIES, INC. - [TitanTest itna01en1-07 BA.fm] - 1807
4. Lift off the cover.
5. Loosen the grounding cable.
6. Loosen the hose connection on the valve clock using a 12 mm open-
ended wrench and remove the hose from the nipple.
7. Use a 17 mm tubular box wrench to remove the fitting with the filter.
8. Clean the filter and mount it on the valve block.
9. Attach the hose to the fitting and tighten the fitting.
10. Connect the grounding cable.
11. Replace the cover and lock the cover with the bolt locks.
12. Insert the mains plug again.
8.6.3 Fan 1
8.6.3.1 Clean / replace filter mat
Clean or replace the filter mat on the bottom of the device if dirty.
8.6.4 Sniffer probe/capillary filter/sinter filter
See the operating instructions for the sniffer probe, Doc. no. ltna01e1
8.7 Replace the ion source
You can replace the ion source through the inspection opening in the chas-
sis bottom of the device without the need to remove the detection system.
1. Switch off the device and pull out the mains plug.
Required material: Cooling Fan Filter T10023
Required material: Ion Source T10059
Required tools: 4 mm Allen Wrench
Damage to the turbo pump from rotating rotor
► The rotor may no longer rotate.
► After switching it off, do not move the TITANTEST™ for at least 4 minutes.
