LACO ORIGINAL OPERATING INSTRUCTIONS TITANTEST™
85
© 2018 LACO TECHNOLOGIES, INC. - [TitanTest itna01en1-07 BA.fm] - 1807
8.8.2 Fuses used
8.9 Sending in the TITANTEST™ for repairs
You can send in your device to LACO Technologies for maintenance or
repairs. For further information on this topic, see Chapter 10.2: "Sending in the
TitanTest™", page 103.
Table 35: Fuses used
Designation Fuse rating Dimensions Function
Main fuse
F T10 A 5 x 20 Mains fuses
Wiring board
F3 T4 A 5 x 20 24 V (main fuse except for TC Power)
I/O Board
F1 T0.8 A 5 x 20 24 V
I
Sniffer connection LP and total
pressure and I/O port
F2 T0.8 A 5 x 20 24 V
III
plug XS4 RC and fan
F3 T0.315 A 5 x 20 not used for
TITANTEST™
MSV
F1 T4 A 5 x 20 24 V of MSV
F2 T4 A 5 x 20 Anode heating
F3 T1 A 5 x 20 24 V DC/DC converter for +5 V/±15 V
F4 M0.032 A 5 x 20 Anode/cathode potential
Table 36: Included fuse set
Designation Value Quantity
G fuse link T 3.15 10
G fuse link T 8.0 G 10
G fuse link M 0.032 C 10
G fuse link T 4.0 10
G fuse link T 0.315 A 10
G fuse link T 0.5 10
G fuse link T 1.0 A 10
G fuse link T 1.6 A 10
G fuse link T 2.0 A 10
G fuse link T 0.8 A 10
G fuse link T 6.3 A 10
G fuse link T 10.0 G 10
G fuse link T 0.2 A 10
G fuse link T 2.5 A 10
