LACO ORIGINAL OPERATING INSTRUCTIONS TITANTEST™

Fig. 30: TITANTEST™ P-Series specific, Chassis Front View * Wet Series Only

Pos. Description Quantity Specifications Order No.

1* P-Series external oil mist filter kit with external oil drain 1 T109514
