ECO GOLD
104 Appendix with settings 25/08/2011/ YACE0088
G.2 Analog module
Analogue Module (LAUDA catalogue no. LRZ 912) has two inputs
and two outputs, which are brought out to a six-pole DIN socket to
Namur Recommendation (NE28).
The inputs and outputs can be set independently of one another as
a 0...20 mA and 4...10 V interface, Various functions can be se-
lected for the inputs and outputs. Accordingly, the signal on the
input is interpreted differently and different information appears on
the output.
In addition the interfaces can be freely scaled according to the set
function. 20 V DC is available for measurement transducers.
The following values can be defined via the inputs:
Set-point temperature Setpoint temperature
Ext. Actual temperature External actual temperature
Pump power Pump power
The following values can be output via the outputs:
Set-point temperature Set-point temperature
Controlled temp. The temperature to which the system is being controlled.
Internal temp. Actual temperature (bath temperature)
Temp.extern Pt100 External actual temperature of Pt100
Temp.extern analog External actual temperature of the analogue input
Temp.extern serial External actual temperature of the serial interface:
Set value Set value
Pump power Pump power
Pump speed Pump speed
In addition the interfaces can be freely scaled according to the set function with minimal value and
maximal value.
For example: 4 mA corresponds to 0 °C and 20 mA corresponds to 100 °C.
Accuracy of the inputs and outputs after calibration better than 0.1 % of full scale.
Inputs, current
Inputs, voltage
Outputs, current
Outputs, voltage
Input resistance < 100 Ohm
Input resistance > 50 kOhm
Burden < 400 Ohm
Load > 10 kOhm
