ECO GOLD
58 Maintenance 25/08/2011/ YACE0088
8.3.4 Cleaning the condenser
8.3.4.1 Air-cooled condenser
The cooling circuit is largely maintenance-free. Remove
dust and contamination from the condenser at regular in-
tervals (depending on operating period and exposure con-
ditions).
− To do this, remove the front grille by grasping it at the
bottom with both hands and pulling the grille to the
front. To avoid damage, remove the front grille slowly
and carefully.
− Then brush down the condenser and, where neces-
sary, blow it out with compressed air.
Note:
Caution !
Contact with sharp-edged vanes on the condenser
during cleaning
Cuts
• Clean the condenser with suitable tools (e.g. hand
brushes, compressed air...).
