ECO GOLD
108 Appendix with settings 25/08/2011/ YACE0088
G.4 USB interface
Important: First install the driver and then connect the thermostat to the PC.
G.4.1 Description
The ECO heating and cooling thermostats are equipped with a USB interface at the back of the control
head. This enables the connection of a PC and operation with the thermostat control software Wintherm
Plus. In addition software updates are possible via the USB interface.
The connecting lead is not included in the items supplied. When connecting up, make sure the correct
plug is used.
USB interface
LAUDA makes the drivers specially produced for the USB interface available free of charge for down-
load at http://www.lauda.de.
G.4.2 Installation of the USB driver
The driver is installed once per PC.
Supported operating systems: Windows ME, Windows XP, Windows 2000, Windows VISTA.
Execute the file "LAUDA_ECO_USB_Driver.exe". The window below opens.
1. Select the language and confirm with
OK .
