Lauda E 4 G - Water-Cooled Condenser

ECO GOLD
25/08/2011/ YACE0088 Maintenance 59
8.3.4.2 Water-cooled condenser
To obtain the full coolin
g output, the sieve and water circuit should be cleaned at regular intervals.
Cleaning the plug-in sieve
For regular cleaning (depending on the degree of contamination of the cooling water) plug-in sieve:
− Remove the water supply hose from the device.
− Unscrew the fitting from the device with a 17 AF open-ended wrench and remove the plug-in sieve
from the fitting.
− Clean the plug-in sieve and then insert in back into the fitting.
− Mount the fitting and the water supply hose onto the device.
