Lauda E 4 G User Manual

ECO GOLD
86 Appendix with settings 25/08/2011/ YACE0088
B List of "Alarm and warning codes"
Alarms
Alarm code Meaning
1
Low Level Pump Pump runs too fast (low level)
2
Low Level Pump Low level in the float
3
Overtemperature Overtemperature (T > Tmax)
4
Pump blocked Pump blocked (standstill)
5
Connection Command Remote control unit command triggered in running operation
9
T ext Pt100 External Pt100 actual value is not present.
10
T ext analog External analog actual value is not present.
11
T ext serial External serial actual value is not present.
12
Input Analog 1 Analog module: Current interface 1, interruption.
13
Input Analog 2 Analog module: Current interface 2, interruption.
15
Digital Input Error on digital input
Warnings
Code 0XX Control sys-
tem
Meaning Code 3XX SmartCool Meaning
1 CAN receive overf
Overflow during CAN reception
1 CAN receive overf
Overflow during CAN reception
2 Watchdog Reset
Watchdog reset
2 Watchdog Reset
Watchdog reset
3 T_il limit active
til llmit active
3 adaption missing
No adaption run
4 T_ih limit active
tih llmit active
4 Pressure switch
activated
Pressure Switch in cooling circuit triggered
5 corrupt parameter
Inadmissible internal parameter
5 Clean condenser
Clean condenser
6 corrupt progr
Inadmissible programmer data
6 TO1 out of range
(Klixon)
Injection temperature outside value range
7 Invalid Parameter
Inadmissible parameter in memory
7 Invalid Parameter
Inadmissible parameter in memory
8 CAN system
Problem during internal data interchange
8 CAN system
Problem during internal data interchange
9 Unknown Modul
Unknown module connected
9 Unknown Modul
Unknown module connected
10 SW control too old
Software version of control panel too old
10 SW control too old
Software version of control panel too old
11 SW safety too old
Software version of protection too old
11 SW safety too old
Software version of protection too old
12 SW command too
old
Software version of command remote
control unit too old
12 SW command too
old
Software version of command remote
control unit too old
13 SW cool too old
Software version of cooling module too old
13 SW cool too old
Software version of cooling module too old
14 SW analog too old
Software version of analog too old
14 SW analog too old
Software version of analog too old
15 SW serial too old
Software version of serial too old
15 SW serial too old
Software version of RS232 too old
16 SW contact old
Software version of contact module too old
16 SW contact old
Software version of contact module too old
17 SW Valve 0 old
Software version of solenoid valve too old
17 SW Valve 0 old
Software version of solenoid valve 0 too old
18 SW Valve 1 old
Software version of solenoid valve 1 too old
18 SW Valve 1 old
Software version of solenoid valve 1 too old
19 SW Valve 2 old
Software version of solenoid valve 2 too old
19 SW Valve 2 old
Software version of solenoid valve 2 too old
20 SW Valve 3 old
Software version of solenoid valve 3 too old
20 SW Valve 3 old
Software version of solenoid valve 3 too old
21 SW Valve 4 old
Software version of solenoid valve 4 too old
21 SW Valve 4 old
Software version of solenoid valve 4 too old
26 SW HTC old
Software version of high temperature cooler
too old
26 SW HTC old
Software version of high temperature cooler
too old
27 SW Ext Pt100 old
Software version of external Pt100 too old
27 SW Ext Pt100 old
Software version of external Pt100 too old
33 RTC wrong data
Internal clock defective
33 valve sm0 break
Cable of injection valve 0 defective
41 wrong net voltage
Incorrect mains voltage setting
34 valve sm1 break
Cable of injection valve 1 defective
42 no eco type
Device type not configured
35 valve sm2 break
Cable of injection valve 2 defective
43 no eco voltage
Mains voltage not configured
36 valve sm3 break
Cable of injection valve 3 defective
44 chiller missing
Chiller not running
37 output sm0
Triggering of injection valve 0 defective
45 Diff.voltages
Different mains voltage configured (head
and cooling underpart)
38 output sm1
Triggering of injection valve 1 defective
39 output sm2
Triggering of injection valve 2 defective
40 output sm3
Triggering of injection valve 3 defective
41 sm0 min too small
Start value of injection valve too small
42 no eco type
Device type not configured
43 no eco voltage
Mains voltage not configured
44 chiller missing
Chiller not running
