Lauda E 4 G User Manual

ECO GOLD
25/08/2011/ YACE0088 Appendix with settings 87
Code 1XX Safety sys-
tem
Meaning Code 2XX Command Meaning
1 CAN receive overf
Overflow during CAN reception
1 CAN receive overf
Overflow during CAN reception
2 Watchdog Reset
Watchdog reset
2 Watchdog Reset
Watchdog reset
5 Heat 1 failed
Heater 1 defective
3 Clock Error
Battery fault
6 Heat 2 failed
Heater 2 defective
9 Unknown Modul
Unknown module connected
7 Invalid Parameter
Inadmissible parameter in memory
10 SW control too old
Software version of control panel too old
8 CAN system
Problem during internal data interchange
11 SW safety too old
Software version of protection too old
9 Unknown Modul
Unknown module connected
12 SW command too
old
Software version of command remote
control unit too old
10 SW control too old
Software version of control panel too old
13 SW cool too old
Software version of cooling module too old
11 SW safety too old
Software version of protection too old
14 SW analog too old
Software version of analog too old
12 SW command too
old
Software version of command remote
control unit too old
15 SW serial too old
Software version of RS232 too old
13 SW cool too old
Software version of cooling module too old
16 SW contact old
Software version of contact module too old
14 SW analog too old
Software version of analog too old
17 SW Valve 0 old
Software version of solenoid valve 0 too old
15 SW serial too old
Software version of RS232 too old
18 SW Valve 1 old
Software version of solenoid valve 1 too old
16 SW contact old
Software version of contact module too old
19 SW Valve 2 old
Software version of solenoid valve 2 too old
17 SW Valve 0 old
Software version of solenoid valve 0 too old
20 SW Valve 3 old
Software version of solenoid valve 3 too old
18 SW Valve 1 old
Software version of solenoid valve 1 too old
21 SW Valve 4 old
Software version of solenoid valve 4 too old
19 SW Valve 2 old
Software version of solenoid valve 2 too old
26 SW HTC old
Software version of high temperature cooler
too old
20 SW Valve 3 old
Software version of solenoid valve 3 too old
21 SW Valve 4 old
Software version of solenoid valve 4 too old
26 SW HTC old
Software version of high temperature cooler
too old
27 SW Ext Pt100 old
Software version of external Pt100 too old
Code 4XX Analog mod-
ule
Meaning Code 5XX Serial
(RS232/485)
Meaning
1 CAN receive overf
Overflow during CAN reception
1 CAN receive overf
Overflow during CAN reception
2 Watchdog Reset
Watchdog reset
2 Watchdog Reset
Watchdog reset
9 Unknown Modul
Unknown module connected
9 Unknown Modul
Unknown module connected
10 SW control too old
Software version of control panel too old
10 SW Contr. too old
Software version of control panel too old
11 SW safety too old
Software version of protection too old
11 SW safety too old
Software version of protection too old
12 SW command too
old
Software version of command remote
control unit too old
12 SW command too
old
Software version of command remote
control unit too old
13 SW cool too old
Software version of cooling module too old
13 SW cool too old
Software version of cooling module too old
14 SW analog too old
Software version of analog too old
14 SW analog too old
Software version of analog too old
15 SW serial too old
Software version of RS232 too old
15 SW serial too old
Software version of RS232 too old
16 SW contact old
Software version of contact module too old
16 SW contact old
Software version of contact module too old
17 SW Valve 0 old
Software version of solenoid valve 0 too old
17 SW Valve 0 old
Software version of solenoid valve 0 too old
18 SW Valve 1 old
Software version of solenoid valve 1 too old
18 SW Valve 1 old
Software version of solenoid valve 1 too old
19 SW Valve 2 old
Software version of solenoid valve 2 too old
19 SW Valve 2 old
Software version of solenoid valve 2 too old
20 SW Valve 3 old
Software version of solenoid valve 3 too old
20 SW Valve 3 old
Software version of solenoid valve 3 too old
21 SW Valve 4 old
Software version of solenoid valve 4 too old
21 SW Valve 4 old
Software version of solenoid valve 4 too old
26 SW HTC old
Software version of high temperature cooler
too old
26 SW HTC old
Software version of high temperature cooler
too old
27 SW Ext Pt100 old
Software version of external Pt100 too old
27 SW Ext Pt100 old
Software version of external Pt100 too old
