ECO GOLD
88 Appendix with settings 25/08/2011/ YACE0088
Code 6XX Switch con-
tacts
Meaning Code 7, 8, 9, 10, 11,
16XX Solenoid
valve
Meaning
1 CAN receive overf
Overflow during CAN reception
1 CAN receive overf
Overflow during CAN reception
2 Watchdog Reset
Watchdog reset
2 Watchdog Reset
Watchdog reset
9 Unknown Modul
Unknown module connected
3 No cooling liquid
No cooling liquid present (HTC)
10 SW Contr. too old
Software version of control panel too old
6 no unfill liquid too
hot
No draining, because bath temperature is
too hot (HTC)
11 SW safety too old
Software version of protection too old
9 Unknown Modul
Unknown module connected
12 SW command too
old
Software version of command remote
control unit too old
10 SW Contr. too old
Software version of control panel too old
13 SW cool too old
Software version of cooling module too old
11 SW safety too old
Software version of protection too old
14 SW analog too old
Software version of analog too old
12 SW command too
old
Software version of command remote
control unit too old
15 SW serial too old
Software version of RS232 too old
13 SW cool too old
Software version of cooling module too old
16 SW contact old
Software version of contact module too old
14 SW analog too old
Software version of analog too old
17 SW Valve 0 old
Software version of solenoid valve 0 too old
15 SW serial too old
Software version of RS232 too old
18 SW Valve 1 old
Software version of solenoid valve 1 too old
16 SW contact old
Software version of contact module too old
19 SW Valve 2 old
Software version of solenoid valve 2 too old
17 SW Valve 0 old
Software version of solenoid valve 0 too old
20 SW Valve 3 old
Software version of solenoid valve 3 too old
18 SW Valve 1 old
Software version of solenoid valve 1 too old
21 SW Valve 4 old
Software version of solenoid valve 4 too old
19 SW Valve 2 old
Software version of solenoid valve 2 too old
26 SW HTC old
Software version of high temperature cooler
too old
20 SW Valve 3 old
Software version of solenoid valve 3 too old
27 SW Ext Pt100 old
Software version of external Pt100 too old
21 SW Valve 4 old
Software version of solenoid valve 4 too old
26 SW HTC old
Software version of high temperature cooler
too old
27 SW Ext Pt100 old
Software version of external Pt100 too old
Code 17XX Pt100/LiBus Module Meaning
1 CAN receive overf Overflow during CAN reception
2 Watchdog Reset Watchdog reset
3 Ext_Pt_short Line short on external t100
7 Invalid Parameter Inadmissible parameter in memory
8 CAN system Problem during internal data interchange
9 Unknown Modul Unknown module connected
10 SW Contr. too old Software version of control panel too old
11 SW safety too old Software version of protection too old
12 SW command too old Software version of command remote control unit too old
13 SW cool too old Software version of cooling module too old
14 SW analog too old Software version of analog too old
15 SW serial too old Software version of RS232 too old
16 SW contact old Software version of contact module too old
17 SW Valve 0 old Software version of solenoid valve 0 too old
18 SW Valve 1 old Software version of solenoid valve 1 too old
19 SW Valve 2 old Software version of solenoid valve 2 too old
20 SW Valve 3 old Software version of solenoid valve 3 too old
21 SW Valve 4 old Software version of solenoid valve 4 too old
26 SW HTC old Software version of high temperature cooler too old
27 SW Ext Pt100 old Software version of external Pt100 too old
