ECO GOLD
25/08/2011/ YACE0088 Appendix with settings 115
Command Meaning
IN_MODE_02 Standby operation: 0 = Device ON / 1 = Device OFF.
IN_MODE_03 Keypad remote control unit Command: 0 = released / 1 = locked.
IN_MODE_04 Setpoint offset source: 0 = normal/ 1 = ext. Pt/ 2 = ext. Analog/ 3 = ext. Serial.
TYPE Interrogation of the device type (response = "ECO")
VERSION_R Interrogation of the software version number of the control system.
VERSION_S Interrogation of the software version number of the protection system.
VERSION_B Interrogation of the software version number of the Command remote control.
VERSION_T Interrogation of the software version number of the cooling system.
VERSION_A Interrogation of the software version number of the analogue module.
VERSION_V Interrogation of the software version number of the RS 232/485 module.
VERSION_D Interrogation of the software version number of the digital module.
VERSION_M_0 Interrogation of the software version number of the solenoid valve (cooling water).
VERSION_M_3 Interrogation of the software version number of the solenoid valve (shut-off valve 1).
VERSION_M_4 Interrogation of the software version number of the solenoid valve (shut-off valve 2).
VERSION_M_5 Interrogation of the software version number of the high temperature cooler.
VERSION_E Interrogation of the software version number of the external Pt100 module.
STATUS Interrogation of the device status 0 = OK, -1 = Error.
STAT Interrogation of the error diagnosis response:
XXXXXXX → X = 0 no error, X = 1 error
1st character = Error
2nd character = Alarm
3rd character = Warning
4th character = Overtemperature
5th character = Low Level
6th character = 0
7th character = External control value missing
RMP_IN_00_XXX Interrogation of a program segment XXX
(Response: e.g. 030.00_00010_005.00_001.00 => Set-point temperature = 30.00 °C,
Time = 10 min, Tolerance = 5,00 °C, Pump stage = 1).
RMP_IN_01 Interrogation of the current segment number.
RMP_IN_02 Interrogation of the set program loops.
RMP_IN_03 Interrogation of the current program loops.
RMP_IN_04 Interrogation of to which program further commands refer.
RMP_IN_05 Interrogation of which program is currently running (0 = none).
LOG_IN_00_XXXX Interrogation of a measurement point XXX from data logger
(Response: e.g. 020.00_021.23_030.50 => Set-point temperature = 20.00 , bath
temperature = 21.23 °C, external temperature = 30.5 °C).
LOG_IN_01 Interrogation of all measurement points from data logger
In contrast to the command "LOG_IN_00" a tabulator character is used here as delim-
iter instead of '_'. The measurement points are separated by CR and LF. The end is
signaled by CR LF CR LF.
LOG_IN_02 Interrogation of starting time of data logger
(Response: e.g. 20_14_12_20 => Day 20, 14:12:20 hrs.).
LOG_IN_03 Interrogation of acquisition interval from data logger (Response in seconds).
Note:
− For ”_“ ” ” (space character) is also admissible.
− Unless otherwise stated, with the command the response is always in the fixed-point format
"XXX.XX" or for negative values "-XXX.XX" or "ERR_X" (RS 485 interface, e.g.
"A015_XXX.XX" or "A015_ERR_X"
