ECO GOLD
90 Appendix with settings 25/08/2011/ YACE0088
With Rec. interval you define the time interval between re-
corded temperature measurements (the values in brackets
state the maximum recording time).
The menu offers five options.
With Time axis you can define the temporal range over which
the measurements are to be displayed.
− automatic Program optimized display
− 9 min time axes set manually
− 45 min (depending on recording interval
− 2 h 15 min up to 144 h)
You can set the scaling to be used via the menu point "Time
base".
− absolute Reference current time
− relative Start time "00:00:00"
With Temperature Scale you can define the scaling of the y axis
(temperature value).
− automatic Program optimized scaling
− manual Here you can define the limits
yourself.
Note: The temperature limits are entered via the menu point Temperature Limits. This menu point only
appears in the graphics menu when manual has been selected in the menu Temperature Scale.
ESC
סּ OK
Standby
Rec. Interval
2 s (max.2h 10min)
10 s (max.11h 5min)
30 s (max.33h 20min)
1 min (max.66h 40min)
2 min (max.133h)
ESC
סּ OK
Standby
Time axis
automatic
9 min
45 min
2 h 15 min
ESC
סּ OK
Standby
Time base
absolute .
relative
ESC
סּ OK
Standby
Temperature scale
automatic .
manual
