170 WM-OM-E Rev I
pkpk
top
base
Standard Horizontal Parameters
These are the default Standard Horizontal Parameters:
Horizontal
freq
period
width
rise
fall
delay
duty
npoints
My Measure
You can choose to customize up to eight parameters by touching My Measure.
Parameter Math (XMath or XMAP option required)
The instrument gives you the ability to perform arithmetic operations (addition, subtraction,
multiplication, division) on the results of two parameter measurements. Alternatively, you can apply
math to a single parameter (for example, invert). By customizing parameters in this way, you can
effectively extend the range of parameter measurements based on your particular needs.
Logarithmic Parameters
The parameter math feature prevents multiplication and division of parameters that return
logarithmic values. These parameters are as follows:
• auto-correlation signal-to-noise ratio (ACSN)
• narrow-band power (NBPW)
• media signal-to-noise ratio (MSNR)
• residual signal-to-noise ratio (RSNR)
• top-to-base ratio when the units are in dB (TBR)
