1. Select the notebook entry from the list box.
2. Touch Flashback.
3. To exit Flashback, touch the Undo Flashback button in the top-right corner of the screen, or
press the Auto trigger button.
Note: The flashback feature currently recalls the scope setup, and all displayed waveforms. Some forms of ‘result data’ are
not recalled, including:
a. Persistence data. This will be saved in the hardcopy, and will be printed in the report, but will not be recalled during
Flashback.
b. Histogram data. Histograms internally have a 32-bit resolution, but when stored into a trace file and recalled during
flashback they are clipped to 16-bits.
c. Floating point waveforms. Certain math operations result in the creation of floating point waveforms with much higher
resolution than can be stored in a 16-bit waveform file. This extra resolution will not be preserved when traces are recalled
using flashback.
d. Cumulative Measurements. Any measurements that are on when the Lab Notebook entry is created are not saved
individually in the database, other than being embedded in the hardcopy image. This means that when flashback is used,
the measurements will be recomputed using the waveform data that was recalled. Normally this will not pose a problem, but
if cumulative measurements were on, which accumulated data from multiple acquired waveforms, they will loose their
history and show instead only the results from the stored waveforms.
Creating a Report
Once the notebook entry is created, you can easily generate a hardcopy report for e-mailing or
printing.
Previewing a Report
Before creating a report, you can preview it by simply touching the View button
. To
exit the preview, touch the Close button at the right of the dialog.
Locating a Notebook Entry
A search filter is provided to help you locate the notebook entry you want to make a report of. You
can search by date or keyword.
