9. Touch inside the Starting at field and enter a starting segment number, using the pop-up

numeric keypad.

Sequence Display Modes

The instrument gives you a choice of five ways to display your segments:

y Adjacent

y Waterfall (cascaded)

y Mosaic (tiled)

y Overlay

y Perspective

Default Chapter3
