4. OVERVIEW OF THE INSTRUMENT
Controls of the Leica STP8000
1 Touch Screen
2 Information key
3,4 Variable function keys, user-programmable
5 Fine focus adjustment
6 Coarse focus adjustment
7 Movement in y-direction
8 Movement in x-direction
4.4.5 Leica STP4000/8000 external control panel
The Leica STP4000 enables remote control of all automated
microscope functions using an external Touch Screen. The
Leica STP8000 control panel also enables monitoring in X, Y
and Z and has user-definable function keys.
Separate instructions are provided for operation of the
Leica STP4000/8000.
Navigation bar Menu barControl panel
Touch Screen for STP4000/8000
Leica STP4000
12
3
4 5
7
6
8
37
