Leica DMi8 - Additional Control Elements

4. OVERVIEW OF THE INSTRUMENT
4.4.2 Additional control elements
Left side of the Leica DMi8 with a fixed Transmitted Light
arm
1 Filter receptacle
2 Aperture Diaphragm Adjustment
3 Stop lever for condenser height adjustment
4 IMC or light ring slide
5 Bertrand lens centering
6 Toggling the top port and Bertrand lens
7 Manual objective change
8 Left side port
9 Manual filter change
10 Focusing
11 Brightness adjustment
12 IMC module
Left side of the Leica DMi8 with a tiltable Transmitted Light
arm
1 Illuminated field diaphragm adjustment (motorized or
manual)
2 Condenser height adjuster
3 Swinging in the polarizer
4 Aperture Diaphragm Adjustment
5 Condenser setting
6 Condenser height stop
1
2
4
5
6
7 9
10
3
8 11 12
1
3
4
2
5
6
31
