5. OPERATION - MAGNIFICATION CHANGER
5.9 Magnification Changer
Leica DMi8 with manually encoded Magnification Changer
As an option, a mechanical Magnification Changer can be
used.
Magnification factors: 1x; 1.6x
t6TJOHUIFTMJEFCBSUPHHMFCFUXFFOYBOEUIFNBHOJmDB-
tion factor.
Note:
The mechanical Magnification Changer works on the eye-
piece and the top port.
Leica DMi8 with motorized Magnification Changer
As an option, a motorized Magnification Changer with 2 or 3
switch positions can be used.
Magnification factors:
For 3 switch positions: 1x ; 1.6x; 2x
For 2 switch positions: 1x ; 1.6x
Setting the Magnification Changer via the Touch Screen:
t6TFUIF
key to switch to the Magnification menu.
t4FMFDUUIFNBHOJmDBUJPOGBDUPSVTJOHUIFDPSSFTQPOEJOH
key.
Note:
The selected factor is included in the calculation of the to-
tal magnification.
Note:
The motorized Magnification Changer works on all ports.
