9. APPENDIX – ASSIGNING THE VARIABLE FUNC TION KEYS
9. Appendix
9.1 Assigning the variable function keys
The variable function keys can always be defined by the
user via the LAS X software.
Depending on the configuration, useful functions are al-
ready assigned to the function key upon delivery.
Preassigning the function keys:
Biological applications
Microscope with Magnification Changer:
Button 1 TL
Button 2 Photo
Button 3 Toggle Magnification Changer
Button 4
Toggle bottom port (if present)
Otherwise: Port switchover
Industry applications
Microscope with Magnification Changer:
Button 1 TL
Button 2 Photo
Button 3 Toggle Magnification Changer
Button 4 Toggle ports
Button 1
Button 2
Button 3
Button 4
Biological applications
Microscope without Magnification Changer:
Button 1 Switch through objectives to the right
Button 2 Photo
Button 3 Switch through objectives to the left
Button 4
Toggle bottom port (if present)
Otherwise: Port switchover
Industry applications
Microscope without Magnification Changer:
Button 1 Switch through objectives to the right
Button 2 Photo
Button 3 Switch through objectives to the left
Button 4 Toggle ports
