5. OPERATION - STAGES AND OBJECT DISPLACEMENT
Up to 5 stage positions and one load position (L) can be
stored.
t4FMFDUJOHTUPSFEQPTJUJPOTVTJOHUIF+ and – keys
t4BWJOHUIFDVSSFOUTUBHFQPTJUJPOVOEFSUIJTOVNCFSVTJOH
the key
If a stage position was previously saved in this location, it
will be overwritten.
t.PWJOHUPUIFDVSSFOUTUPSFEQPTJUJPOVTJOHUIF
key
When driving to the load position, the objective nose-
piece is raised to the lower threshold.
Note:
If a stored position is outside the travel range of the stage,
for example as a result of subsequent changes to the travel
range in the LAS software, you must restore the maximum
range of the stage via
Limits
to reach the position.
The stored positions will be saved until the microscope is
switched off and are deleted after a restart.
