5. OPERATION - APERTURE AND ILLUMINATED FIELD DIAPHRAGM
Leica DMi8 with motorized aperture and illuminated field
diaphragm
Both diaphragms have been set to suitable values for the
current objective and contrast method at the factory.
t6TJOHUIFAperture (aperture diaphragm) or Field (field
diaphragm) keys, the motorized diaphragms can be
changed at any time. The display on the Touch Screen
changes accordingly.
Note:
The old values will be overwritten by the current ones!
Note:
When using PH or DF, the aperture diaphragm is open all
the way and cannot be closed.
Setting the diaphragms via the Touch Screen
t0OUIF5PVDI4DSFFOVTFUIF
key for basic micro-
scope settings.
t4FMFDUUIFStatus/Illumination menu using the
key.
t"EKVTUUIFBQFSUVSFBOEmFMEEJBQISBHNTVTJOHUIF+ and
– keys.
61
